TIG Torch Cooling System

///TIG Torch Cooling System

TIG Torch Cooling System

Specifications

  • Factory set at 50 psi
  • 2 gallon reservoir
  • 115 or 230 VAC / 1 ph – 50 / 60 Hz
  • 3.2 / 1.5 amp : 60 Hz
  • 10,000 BTU
  • Dimensions: 12”L x 14”W x 9”H
  • Net weight: 30 lbs / 13.6 kg
  • Foam packed for UPS shipment
  • 0.8 gpm @ 50 psi

System Features

  • Plastic water tank eliminates coolant contamination due to electrolysis or chemical reactions.
  • All units are plumbed with copper tubing and reinforced hose.
  • New extended life pump features a direct drive power system reducing maintenance and vibration.
  • No external plumbing is required because of closed loop water system.
  • Self priming pump
  • Easy change pump
  • Strong rigid construction designed to support power unit.
  • Compact design
