Specifications

  • Factory set at 50 psi adjustable to 80 psi
  • 10 gallon reservoir
  • 115 or 230 VAC / 1 ph-50 / 60 Hz
  • 5.6 / 2.8 amp: 60 Hz
  • 15,000 BTU
  • Dimensions:23″ L x 11″ W x 20″ H
  • 1/4 FPT(water in /out) with 5/8″LH Standard Inert Gas Fitting
  • Net weight: 48 lbs/22 kg
  • Foam packed for UPS shipment

R1200 G: Rotary GEAR Pump

  • 1.8 gpm at 50 psi
  • Built in by-pass to tank.

R1200 V: Rotary VANE Pump
1.7 gpm at 50 psi
